Jet/asian 10" tilting arbor saw ctas-10 parts manual
10-inch Tilting Arbor Saw CTAS-10
This is a reproduction, not a photocopy, of an original JET CTAS-10 10-inch Tilting Arbor Saw Instructions and Parts Manual. This manual contains operating instructions, adjustments, maintenance, and a complete set of exploded view diagrams of the parts with description. Please read index below.
Introduction...............................1
Specifications.............................2
Features...................................2
Unpacking and Cleanup......................4
Safety Suggestions.........................4
Installation and Levelling.................4
Assembling Guide Rails.....................4
Assembling Blade Guard and Splitter........5
Connecting to Power Supply.................7
Raising the Blade..........................7
Tilting the Blade..........................8
Adjusting the Table........................9
Adjusting Rip Fence........................9
Adjusting Table Insert....................10
Adjusting Miter Gauge.....................10
Removing Saw Blade........................11
Adjusting Rip Fence Flush to Saw Table....11
Assembling Wood Facing to Rip Fence.......12
Access Door...............................12
Preliminary Operator Instructions.........12
Cross Cutting.............................12
Ripping...................................13
Rust Prevention...........................13
Adjustment Mechanisms.....................14
Frame Assembly............................16
Blade Guard...............................18
