Nice harig #612 precision manual surface grinder
NICE!! HARIG #612 PRECISION MANUAL SURFACE GRINDER
Made in the U.S.A. by Harig Products Inc. of Elgin, Illinois.This is a Manual Surface Grinder in working condition.Model #: 612Serial #: R10914
* Allen Bradley 1305 Speed Control.
* All castings are 30,000 psi graphitic iron to resist deflection under load.
* Harig's hand-scraped vee and flat way design compensates for wear and maintains a perfect fit for prolonged, accurate machine life.
* Telescoping guarded elevating screw is centered between column ways for smooth operation.
Table Size: 6" x 12"Travels:
Longitudinal Travel (X-Axis): 17"
Cross Feed Travel (Y-Axis): 6 1/2"
Vertical Wheelhead Travel (Z-Axis): 11"Wheelhead:
Grinding Wheel Furnished: 6"
Max. Vertical Working Height (under 6" wheel): 10"
Elevating Handwheel Graduations: .0005"
Cross Feed Handwheel Graduations: .001"Spindle Motor:
R.P.M.: 3,450 / 2,850General:
Overall Dimensions: 35" x 40" x 77" tall.Comes as shown in pictures.
