5MP camera w stereo boom stand microscope 144 led light
Boom Stand Trinocular 3.5x~90x Zoom Stereo Microscope
with 2592x1944 (5.0 Megapixel) USB Digital Camera
* Zoom lenses 3.5x~90x, crystal clear at any point
* Extremely long working distance and field of view with 0.5x auxiliary lens
* 2592x1944 (5.0 Megapixel) high resolution digital camera
* Long lifetime cold 144 LED illumination with extra metal 50mm thread ring light adapter
* Eyepieces: super wide field SWF10X/20 and WF20X
* Total magnification: 3.5x~90x
* Working distance: 3-3/4" (95mm) without 0.5x auxiliary lens and 6" (152mm) with 0.5x auxiliary lens
* Field of view: Max 1-1/8"(28mm) without 0.5x auxiliary lens and Max 1-3/4" (44mm) with 0.5x auxiliary lens
* Diameter of ring light or auxiliary lens mount: 50mm female thread
* Focusing adjustment range: 2-3/8" (60mm)
* Resolution: true color 2592x1944 pixels
* Frame Speed: 8fps at 2592x1944, 30fps at 640x480
* Date Transfer Rate: 480Mb/s
* Compatible with Windows 2000/XP/Vista32 (64 bit Vista is not supported)
* Eyetube conversion adapter with rubber ring fits 30mm and 30.5mm for stereo microscopes
* Date Output: USB 2.0 high speed
* USB 2.0 cord: 6 feet (1.83m)
* Sturdy metal shell 144 LED white bright ring light, variable intensity
* Matching objective housing size in diameter: 1" ~ 2.4" (25 mm ~ 61 mm)
* Power supply: Input 90V ~ 265V AC 50Hz/60Hz, Output 12V DC
* Extra metal 50mm thread ring light adapter
* Base size: 10" x 10" (25.4cm x 25.4cm)
* Dimension: 26" x 10" x 16" (66cmx25.4cmx40.5cm)
* Trinocular stereo zoom microscope
* A pair of SWF10X/20 eyepieces
* Eyetube conversion adapter with rubber rings
* Boom stand (head holder diameter 84mm)
* USB 2.0 digital camera 2592x1944 with 0.5x built-in reduction lens
* 144 LED ring light with power adapter and power cord
* 1 piece 50mm thread ring light metal adapter
