TL071 jfet op-amp ic kit w/ pcb (#1875)
TL071 JFET Op-Amp IC Kit w/ PCB (#1875)
This is the TL071 Single JFET Op Amp DIP IC Design Kit #1. It includes 4 pieces of the very popular Texas Instruments TL071CN JFET Op Amp in a DIP-8 package. This Op Amp has been used for decades and you can find it in quality audio circuits! The datasheet can be found at .
This kit also includes various quantities of 1/4 Watt Carbon Film Resistors, Ceramic & Aluminum & Tantalum Capacitors, Signal & Power Diodes, LEDs, various Trimpots, Electret Microphones, a miniature Speaker, EMI Filter, and some Electronic Hardware to interface to the real world.
To further help with your circuit development, you also get a 162 plated-thru hole PCB and some IC sockets. This PCB has 4 mounting holes, is 1.1" x 2.0", and is double-sided. With these parts, you can make numerous circuits such as active filters, pre-amps, signal conditioners, function generators and much more. Search the web for incredible circuits to build. The Datasheets and Application Notes for the ICs and Transistors, along with hundreds of others, are located at DATASHEETS. We supply the parts, you supply the ingenuity. You get the following:
2N3904, NPN, GP Amplifier, TO-92
2N3906, PNP, GP Amplifier, TO-92
162 Holes, Double-Sided, .062" Thick, FR-4
