220 mhz repeater 20 watts
Recent Price Increase due to change in the value of the US Dollar versus the Australian Dollar
Continous duty - Used in Trunking applications, general dispatch operation, paging or data, ideal for settng up a reliable 220 Amateur Repeater.
This unit is listed as refurbished only due to the fact that we will have to configure to your specifications and that may require some filter changes etc. This is new or demo stock and will be fully guaranteed. What is shown in the picture composes this offer.
99 Channel Binary Selectable, 20 Watt Exciter, accessory access by means of back plane connections for COR, Line I/O, Detector out, PTT, Audio I/O, and many other functions. RF Terminations are type N female.
This is a very versatile piece of hardware. 19" rack mount, 4 units high, can immediately be set up as a single channel (CTCSS/DCS controlled ) repeater, or a multi channel base station. ( For Base Station an antenna switch is required ) No controller is required. This unit is available as a Narrow Band or Wide Band (20K0F3e) station. These modules are programmed by means of a PC / software to include monitoring of functions and diagnostics. These accessories are available at additional cost(s).
Modules included are 1- R220 receiver, 1- T220 Exciter capable of 20 watts stand alone, and 19" rack configured for power supply and power amplifier which can be purchased later or separately. These will operate from 12 Volt DC out of the box. All connections and interfac points are accessable and simple to connect. If used as a repeater all that is required to be operational is a duplexer and 12 Volts @ 15 amps. If a power amplifier is desired to be integrated a hgher capacity power supply is required.
Other range modules are available for x-band link or repeater.
This item can be supplied in quantity if desired !
Single channel programming included. We can quote for multi channel if desired.
Not included: Duplexer, controller or remote panel. These are available at extra cost based upon requirements / specifications.
We invite your questions about this equipment line
WE EXPORT AND ARRANGEMENTS CAN BE MADE ACCORDINGLY
