Keyence lk-G3001 ccd laser sensor controller w/display
Keyence LK-G3001 CCD Laser Sensor Controller w/Display
This is a Used Keyence CCD Laser Displacement Sensor Controller Unit-LK-G3001. This is the Separated Display Styled unit. This is just the controller unit and LK-GD500 display. The sensors are sold separately in order to build the setup. When the controller is attached to sensors and PC, it is used for accurate measurements in applications like: thickness inconsistency of a wafer, measuring the run out of a hard drive, scanning liquid crystal surfaces. It features 50KHz speed, .03% accuracy, 0.02 Mil repeatability, and a 5.91" max distance range.
Cosmetically, the item is in good condition with no major wear. The photos show a typical item for sale. Only what is shown in the photos is included.
* Model: LK-G3001 Controller
* This model can be operated by itself
* 65,000-point memory is integrated internally in order to store the 50 kHz ultra-high-speed sampling data
* Multiple I/O requires no optical parts
* Five types of I/O including USB are available as standard
* Compatible with all LK-G Series Sensors and Cables
* Power supply voltage: 24 VDC 10%, Ripple: 10% (P to P) or less
* Current consumption: 500 mA or less with 1 head/600 mA or less with 2 heads
* Ambient temperature: 0 to +50 C (32 to 122 F), No condensation
* Relative humidity: 35 to 85%, No condensation
