Honeywell THX9321R5000 prestige hd thermostat
Includes: 1 Kit Honeywell THX9321R5000 Prestige HD Thermostat
Honeywell THX9321R5000 Prestige HD Thermostat
NOTE - THIS IS A WIRED THERMOSTAT - IT REQUIRES 24V COMMON WIRE. Accessories (example - Outdoor Sensor) are wireless but wired connection with 24V "common" must be made between thermostat and heating/cooling equipment. CLICK HERE TO LEARN MORE ABOUT WIRING THIS THERMOSTAT
Large, easy-to-read backlit display shows current indoor temperature and humidity, temperature setting, date and time on the home screen. Also displays outdoor temperature and humidity on home screen (if wireless outdoor sensor is installed)
Adjustable backlight level allows thermostat to be on full brightness at all times or dim to the brightness level of choice when the thermostat is not being used
Interview-Based Programming wizard to easily and confidently schedule thermostat temperatures and times
USB Port allows downloading of installer settings to quickly and consistently perform setup of thermostats in similar applications
USB Port also allows easy setup of dealer logo and contact information on thermostat screen
Real-Time Clock keeps time during power failure; automatically updates for daylight saving time
Precise Temperature Control (+/- 1 F) for reliable and consistent temperature.
Multiple HOLD options allows modification of schedule as needed
Change Reminders to inform it is time to replace Air Filter, humidifier pad, ultraviolet bulb or batteries in connected devices
RedLINK Enabled to communicate with compatible wireless devices
Provides humidifier and dehumidifier control
Description - Honeywell THX9321R5000 Prestige HD Thermostat
Application - Up to 3 Heat/2 Cool Heat Pump or Up to 2 Heat/2Cool Conventional
Programmability - 7-Day Multiple Day Programming or Non-Programmable
Terminal Designations - C, R, Rc, W-O/B, W2-AUX/E, Y, Y2, G, L, K, HUM, HUM, DHM, DHM
Electrical Ratings - 18 to 30 Vac
Electrical Connections - Screw terminals
Operating Temperature Range (F) - 32 F to 120 F
Operating Temperature Range (C) - 0 C to 48.9 C
Setting Temperature Range (F) - Heat: 40 F to 90 F; Cool 60 F to 99F
Setting Temperature Range (C) - Heat: 4.5 C to 32.0 C; Cool: 15.5 C to 37.0 C
Humidity Setting Range - Cooling: 40 to 80% RH. Heating: 10 to 80% RH.
Stages - Up to 3 Heat / 2 Cool Heat Pump or Up to 2 Heat / 2 Cool Conventional
Operating Humidity Range (% RH) - 0 to 90% RH, non-condensing
Comments - Tri-Lingual Display (selectable for English, French or Spanish)
Used With - RedLINK enabled thermostats and accessories
Thermostat Dimensions: 7" W x 4" H x 1-1/2" D
Humidification Setting Range - 10 to 60% RH.
Dehumidification Setting Range - 40 to 80% RH.
