Burndy Y39 12 Ton Hydraulic Hand Operated Crimper
The Y39 weighs 13 lbs., and its small 3-1/8" wide head rotates 180 for convenience and flexibility.
The tool provides 12 tons of crimping power.
Built-in overload valve automatically releases pressure when the crimp is completed.
Easy to work in small tight spaces with only a 3-1/8" wide compression head and short handle throw
Easy to position tool for work with 180 head rotation
Works on all commonly used copper and aluminum conductors from #6 str. to 750 kcmil
Body and handles covered with 3/16" rubber
Easy to locate and hold dies in position with the positive push button die locks
Die changing is accomplished easily without ball checks or set screws
Easy to remove or lock into position die holder with recessed spring latch plus leather strap to prevent loss
Automatic 10,000 psi "blow off" pressure release valve for positive crimping
Rapid ram advance eliminates requirement for pumping handles to advance ram to connector
Trigger release allows ram to return to preset position
Long contnuous usage is aided with comfort grip handles
Compression terminal, tap and splice connectors are
UL listed and CSA certified when installed with the Y39 tool and recommended die set
Like new condition, works perfect
May have been used a couple of times, hardly a scratch
