National instrument scxi-1193 multiplexer/matrix module
The National Instruments SCXI-1193 is a high-density 50 RF relay module. It can be programmatically configured as an unterminated multiplexer, externally terminated multiplexer, or dimensionally flexible sparse matrix. It is still in perfect working condition, Like-New. Product Condition:Used Like New
This card was recently pulled out from an engineering lab. It is still in perfect working condition, Like-New. The National Instruments SCXI-1193 is a high-density 50 RF relay module. It can be programmatically configured as an unterminated multiplexer, externally terminated multiplexer, or dimensionally flexible sparse matrix. Each configuration handles signal frequencies from DC to beyond 500 MHz. This single-slot switch module uses high-density push-on MCX connectors for discrete yet manageable cabling. The NI SCXI-1193 module is designed to integrate with high-frequency instruments such as the NI PXI-5404 frequency generator and the NI PXI-5112 high-speed digitizer.
* Fully software configurable
* OS Support Windows, Real-Time, Linux
* LabVIEW RT Support Yes
* Switch Type Multiplexer, RF
* Relay Type Electromechanical
* Product Certifications C-Tick, CAN/CSA, CE, FCC Part 15, IEC, UL - Product Safety
* Multiplexer Configurations 32x1, 1-wire 2 banks of 16x1, 1-wire 4 banks of 8x1, 1-wire 9 banks of 3x1, 1-wire
* Maximum Switching Voltage DC (Pollution Degree 2) 150 VDC
* Maximum Switching Voltage AC 150 Vrms
* Maximum Switching Current 0.5 A
* Maximum Carry Current 1 A
* Maximum Switching Power 10 W
* Relay Count Tracking Yes
* Voltage Category CAT I
* VSWR (Typical) 1.4 @ 200 MHz
* Isolation (Typical) 80 dB
* Insertion Loss (Typical) 0.9 dB
* Characteristic Impedance 50 Ohm
* Mechanical Relay Life 5 x 107 cycles
* Scan Rate 110 cycles/s
* Timing/Triggering/Synchronization
* Synchronization Bus (RTSI) Yes
* T-clock Capability No
* National Instruments SCXI-1193 Multiplexer/Matrix Module
* Software and Accessories not included
