Vynckier clear cover electric box enclosure 12 x 10 in.
Vynckier Clear Cover Enclosure
CVJ Series Enclosure with 2 Stainless Steel Twist Latches and a Stainless Steel Piano Hinge
Clearview Bonded Window on Cover
All CVJ Series enclosures are designed to meet the Joint Industrial Council (JIC) standards in the United States.
CVJ's are made from corrosion resistant hot compression molded fiberglass reinforced polyester with transparent lexana window. These enclosures do not contain halogens.
The CVJ series "HWLL" enclosures include one or two stainless steel twist latches to secure one side of the cover to the base and a stainless steel piano hinge that secures the other. Rivets connect the hinge to the cover and self-tapping screws connect the screws to the base.
Vynckier's CVJ enclosures are capable of withstanding continuous temperatures from -58 F (-50 C) up to 302 F (150 C).
CVJ enclosures are capable of equipment and operators from indirect electrical contact.
All CVJ enclosures are UL listed per UL Standard 508 for NEMA 3, 3R, 4, 4X, 12 and 13; CSA Certified per Standard C22.2-0, 0.4, 0.7, 0.6, 94 Type 3, 3R, 4, 4X, 12 and 13.
This box is used but in excellent condition!
