4" spdl 71" x wotan B105M horizontal boring mill, #50PD
4" Spdl 71" X Wotan B105M HORIZONTAL BORING MILL, #50PD
4" Spindle 71" X Axis Wotan B105M HORIZONTAL BORING MILL, #50PDB,RotaryTbl,3-Axis MitutoyoDRO,TeleSc
4" WOTAN TABLE TYPE HORIZONTAL BORING MILL
MODEL B100M, S/N: 52498, NEW 1972
SPINDLE DIAMETER.......................... 4"
TABLE SIZE ............................... 44" X 55"
TABLE CROSS TRAVEL (X-AXIS) .............. 71"
SPINDLE-HEAD VERTICAL TRAVEL (Y-AXIS) .... 60"
SPINDLE (QUILL) TRAVEL (Z-AXIS) .......... 23-1/2"
SADDLE LONGITUDINAL TRAVEL (W-AXIS) ...... 60"
SPINDLE TAPER ............................ #50 NMTB
SPINDLE HORSEPOWER ....................... 20 HP
SPINDLE SPEED RANGE ................ 12.5 TO 1000 RPM
TABLE LOAD CAPACITY ...................... 8,800 LBS.
APPROXIMATE MACHINE DIMENSIONS ........... 17'5"L X 10'8"W
APPROXIMATE MACHINE HEIGHT ............... 11'7"
APPROXIMATE MACHINE WEIGHT ............... 35,000 LBS
- #50 TAPER SPINDLE WITH POWER DRAW BAR
- 44" X 55" BUILT-IN ROTARY TABLE
- MITUTOYO 3-AXIS DIGITAL READOUTS
- TELESCOPIC STEEL WAY COVERS FOR BED & SADDLE TRAVELS
UPDATED ELECTRICS WITH PLC IN 2000
