Eutech ECCONCTP1002 conductivity controller; 230V,
EUTECH ECCONCTP1002 CONDUCTIVITY CONTROLLER; 230V,
This item is a new in box Eutech Instruments 1/4-DIN series COND 1000 Conductivity Controller (model ECCONCTP1002). This controller is powered with 220 VAC, 50/60 Hz power.
This controller features reversible 0/4-20 mA output, whichmakes it ideal for proportional control or datalogging. The control type can be either On/off, proportional, or pulse length / pulse frequency. It also features two control relays and an alarm output with delay for greater flexibility. User selectable cell constants allow unit to be used over a wide range. An adjustable temperature coefficient provides excellent accuracy for all types of solutions. All connections are made through a detachable terminal strip. Controllers measure 3 13/16 inches Wide x 3 13/16 inches High x 6 15/16 inches Deep.
NOTE: THE CONDUCTIVITY PROBES AND CELLS WITH 100 OHM Pt RTD or 1000 OHM Pt RTD temperature compensation ARE NOT INCLUDED, AND MUST BE ORDERED SEPARATELY (CAN BE OBTAINED AT COLE-PARMER.COM).
Conductivity range: 0.000 to 1.999 S, 0.00 to 19.99 S, 0.0 to 199.9 S, 0 to 1999 S, 0 to 5000 S, 0.00 to 19.99 mS, 0.0 to 199.9mS
Resolution: 0.001 S to 0.1 mS
Temp compensation: Automatic/manual from -9.9 to 125 C, 100 ohm or 1000 ohm Pt RTD (Linear 0.00 to 10.00% per C)
Output Analog: 0-20, 4-20 mA, reversible with programmable boundaries, 600 maximum load
Output Control :Two SPDT relays, 250 VAC max, 6 A @ 110 VAC
Alarm: One SPDT relay, 250 VAC max, 6 A @ 110 VAC
