Usb long acan laser barcode scanner bar code reader
USB Long Acan laser BARCODE SCANNER BAR CODE READER
* Simple installation , keyboard wedge, serial, wand emulation
* Superior keyboard wedge interface NOVELL compatible auto caps lock detection ensures that the data always appears on the computer just the way it is encoded in the bar code
* Simple programming from your keyboard or scan bar codes!
* Automatically clones decoders in under 10 seconds over 300 decoders per hour
* Auto detection of the type of computer ( PC , XT , PS/2 and XWindow terminals with a PC compatible keyboard interface )
* Supports over twenty different keyboard country layouts.
* Supports editing, operations include ( insert , stripping , filtering , convert case )
* Programmable preamble, postamble, and termination strings
* READ / NO-READ indicators ( Buzzer and LED )
* Extended ASCII support for code 128 bar codes
* Over 180 configurable options
* Can be used with or without the keyboard
* Map bar code to any key on the keyboard
* Macro support ,replace a string in the bar code with another
* Superior reading performance utilizing advanced decoding algorithms
* Operating temperature:0 C-50 C / 32 F to 122 F
* Storage Temperature: -40 C-70 C / -40 F to 158 F
* Relative Humidity:5% -95% ( non condensing )
* Shock:1.5mm drop on concrete surface
* Ambient light immunity: Immune to direct exposure of normal office and factory, lighting conditions, as well as direct exposure to sunlight
* Electrostatic Discharge: Conforms to 15KV air discharge and 8KV of contact discharge
* Safety: CORH class 2 Laser product , FCC class A and CE
* Current consumption:100mA ( Idle current <40mA )
* Voltage Requirement:5VDC 5%
* Scanner Type: Bi directional
* Light Source :650-670nm ( Visible )
* Scan Rate: 100 scans per second
* Resolution:0.10mm ( 4 mile ) PCS0.9
* Reading Distance: 2.5 -600mm ( 100% UPC / EAN )
* Print Contrast : 30% minimum reflective difference
* Dimensions: L160mm x W65mm x H85mm
* Scanning angle: Inclination angle 45 Elevation angle 60
* UPC / EAN with Supplementals
* Interfaces Supported: Keyboard wedge / RS232 / USB
* 1x USB Long scan laser BARCODE SCANNER BAR CODE READER
