1929 earth work surveying retaining stone wall masonry+
This hardback book (and the others from this same series also currently running) absolutely must be seen!! Titled; "EARTHWORK AND RETAINING WALLS" / By Horace R. Thayer / {329B} / Published by INTERNATIONAL TEXTBOOK COMPANY / Copyright 1929 ~~//~~ This easily written and profusely illustrated book is in mint condition. Never even fully opened. The pages are pristine! Tightly bound inside of midnight blue embossed (thin) leather covers, (with cobalt/gold on teal marbled end papers). 58 + vividly detailed figures, diagrams and sharply detailed line cuts are found throughout this text! Depicting all sorts of earthwork including; cantilever wall parts, gravity wall plans, foundation pressure, side-hill curvature, measurement of excavation, cross section cutting +++. Slight surface wear (just barely touching) the cover tips is the only tiny flaw to the outside of this 81-year-old original. That s it! I was unable to find a single flaw to the interior of this 5" by 7 3/4" beauty. That s it! Its 169 + blue edged, heavy cream colored pages have no brittleness foxing sticking mildew wrinkles waving rips tears dogears odor underlines marks of anykind or even a fingeredge smudge.
A complete list of the fascinating sections, (as well as a sample of the many chapters) contained within includes; Earthwork: Field Measurements ~ Definitions; NECESSITY OF CUTTING AND FILLING / USE OF MATERIAL / ROADBED / GRADE LINE + ~ Dimension of Cross-Sections ~ Surveys; SURVEYS FOR DETERMINING GRADE / PRELIMINARY STEPS / DETERMINATION OF RATE OF GRADE / MEASUREMENT FOR EARTHWORK COMPUTATIONS + ~ Earthwork Computations ~ Prismoids; ACCURACY OF COMPUTATIONS AND MEASUREMENTS / PRISMOIDAL FORMULA / LENGTH OF PRISMOID OF EARTHWORK + ~ Three-Level Sections; AREA OF THREE LEVEL SECTION / PRISMOIDAL CORRECTION + ~ Irregular Sections ~ Side-Hill Work ~ Transition from Cut to Fill ~ Misc. Problems; EXCAVATION IN COMPOUND SECTION / BORROW PITS / MEASUREMENT OF EXCAVATION IN IRREGULAR BORROW PITS / ALLOWANCE FOR DITCHES + ~ Condition for Curvature; CURVATURE CORRECTION FOR THREE-LEVEL SECTIONS / CORRECTION OF CURVATURE IN SIDE-HILL WORK + ~ Formation of Embankments; SHRINKAGE / SWELL OF ROCK / SIDE-HILL WORK CORRECTION + ~ Methods of Forming Embankments ~ Mass Diagram ~~~//~~~ Design of Retaining Walls: Stability of Retaining Walls ~ Intro; PARTS OF RETAINING WALLS / POSSIBLE FAILURES + ~ Earth Pressure: ALLOWANCE FOR TRACK LOADS ON FILL + ~ Investigation of Stability: STABILITY AGAINST OVERTURNING / GRAPHIC METHOD / DISTRIBUTION OF PRESSURE ON FOUNDATION / OFFSET AT TOE / SPACING OF PILES / RESISTANCE TO SLIDING AND SHEAR + ~ Methods of Design ~ Types of Retaining Walls; GRAVITY WALLS / REINFORCED CONCRETE WALLS / CONSIDERATIONS IN DESIGN + ~ Design of Gravity Walls; METHOD / DIMENSIONS / PROCEDURE IN DESIGN / SPECS FOR MATERIALS / WALLS WITH CUT STONE FACE / RUBBLE MASONRY / DETAILS ON CONSTRUCTION / WATERPROOFING ~ Design of Reinforced Concrete Walls ~ Features; WIDTH OF BASE / LOCATION OF STEM / BATTER AND TOP WIDTH OF STEM / EXPANSION JOINTS IN REINFORCED-CONCRETE WALLS / DRAINAGE IN "" + ~ Design of Cantilever Retaining Walls; PARTS OF A CANTILEVER WALL / DESIGN OF STEM / DESIGN OF TOE PROJECTION / "" HEEL "" / CONSTRUCTION OF CANTILEVER WALLS / DESIGN SUMMARY + ~ Design of Counterfort Retaining Wall; COMPARISON OF CANTILEVER WITH COUNTERFORT WALL / METHOD OF DESIGNING STEM / DESIGN OF BASE / DESIGN OF COUNTERFORTS / CONSTRUCTION OF COUNTERFORT WALLS / ILLUSTRATIVE DESIGN...with many others, each containing numerous even more specific sub-chapters.
