Gomaco commander iii trimmer paver oper service manual
Gomaco Commander III Trimmer/Paver/Slipform Operator's Service Manual
Controls and Gauges: content of chapter, engine controls and gauges, hydraulic controls and gauges, electrical controls, moving the machine.
Standard Set-Up: content of chapter, curb and gutter form preparation, sidewalk for and prep, monolithic form prep, trimmerhead prep, positioning the legs, preparing and mounting the conveyor, positioning and mounting the trimmerhead, mounting the slipform mold, mounting the sensors (standard) (scab-on) (right side) (lock to grade), preliminary adjustments, final adjustments, pouring operations.
Paving Package Set-Up: content of chapter, prime mover prep (12ft pkg) (16ft pkg), mounting the optional rear leg extension, preparing and mounting the trimmerhead, mounting the sensors, preliminary adjustments for trimming operations, trimming operations, slipform mold prep and mounting, mounting the conveyor, preliminary adjustments for pouring operations.
Side Mounted Barrier Set-Up: content of chapter, form preparation, positioning the legs, mounting the slipform mold, preparing and mounting the conveyor, mounting the sensors, preliminary adjustments, final adjustments, pouring operations.
Maintenance: content of chapter, fuels, lubricants, 10,50,150,300,600,hours of service, servicing the air cleaner, battery service, alternator, regulator and starter Service, adjusting the servo valves, adjusting pressures, adjusting the steering systems, adjusting the slope sensor.
Troubleshooting: contents of chapter, troubleshooting the engine, hydraulic reservoir system, auger system, conveyor system, trimmerhead system, tractive system, vibrator system (early production), the 4 to 8 vibrator sysrem (early production), the vibrator system (current production), hold-down system, hold-over system, auxiliary hydraulic system, grade hydraulic system, front and rear grade electrical systems, the slope (right grade) electrical systems, rear steer hydraulic system, rear steer electrical system, front steer hydraulic system (early production), front and rear steer, hydraulic systems (current production), front steer electrical control system, front steer alignment electrical system (early production), front steer alignment electrical system (current production), miscellaneous electrical systems.
Specifications: content of chapter, engine, capacities, battery, alternator, starter, automated controls, hydraulic system, vibrators, trative system, conveyor system, trimmerhead system, weights and dimensions.
Stringline Set-Up: content of chapter, setting straight line, setting line for radii, positioning stringline for cross slope changes, setting the line under the machine.
This manual is clean & clear to read and has never been used.
