> 28" swg 120" cc tos SN71C engine lathe, inch/metric,gap
28" swg 120" cc tos SN71C engine lathe, inch/metric,gap
28" Swg 120" cc Tos SN71C ENGINE LATHE, Inch/Metric,Gap
28" Swing 120" Centers Tos SN71C ENGINE LATHE, Inch/Metric,Gap,Taper,TrakDRO,3-Jaw,2-Steadies,F
28"/37" x 120" TOS GAP-BED ENGINE LATHE
MODEL: SN71C-3, S/N:471300910383, NEW: 1991
SWING OVER BED ............................ 27.95"
SWING OVER CARRIAGE ....................... 16.53"
SWING OVER GAP ............................ 37.79"
WIDTH OF GAP IN FRONT OF FACE PLATE ....... 11.81"
MAXIMUM WEIGHT OF MACHINED PART ........... 3,300 LBS.
CROSS SLIDE TRAVEL ........................ 15.74"
DISTANCE BETWEEN CENTERS .................. 120"
SPINDLE SPEEDS, IN TWO RANGES (16) ........ 10-1,000 R.P.M.
SPINDLE HOLE .............................. 2.89"
HEADSTOCK SPINDLE CENTER TAPER ............ NO. 5 MORSE
SPINDLE NOSE .............................. CSN20-1011
LONGITUDINAL .......................... .003-.252 I.P.R.
CROSS ................................. .001-.126 I.P.R.
THREADS - INCH (35) ....................... 1-80 T.P.I.
THREADS - METRIC PITCH (29) ............... 0.5-40 MM
TAILSTOCK SPINDLE DIAMETER ................ 3.54"
TAILSTOCK SPINDLE CENTER TAPER ............ NO. 5 MORSE
TAILSTOCK SPINDLE TRAVEL .................. 9.45"
- INCH/METRIC THREADING CAPABILITY
- MOTORIZED POWER RAPID TRAVERSE TO CARRIAGE AND CROSS SLIDE
- #102 SWI TRAK TWO-AXIS DIGITAL READOUT
- 19-1/2" DIAMETER FOUR-JAW CHUCK WITH REVERSIBLE JAWS
- 12" DIAMETER THREE-JAW CHUCK
- 12" DIAMETER CAPACITY THREE-POINT ROLLER-TYPE STEADY REST
- 7" DIAMETER CAPACITY THREE-POINT ROLLER-TYPE STEADY REST
- FOUR-WAY TURRET-TYPE TOOLPOST WITH (1) #CA1 ALORIS TOOL HOLDER
- (1) LIVE CENTER FOR TAILSTOCK
- EXTERNAL COOLANT PUMP AND TANK
- 10 H.P. SPINDLE DRIVE MOTOR AND ELECTRICAL CONTROLS
Click Here For More Tos Machines
