16"/24" x 40" kerrey/namseon gap bed engine lathe, 1987
16"/24" X 40" KERREY/NAMSEON GAP BED ENGINE LATHE, 1987
REMOVABLE GAP BED ENGINE LATHE,
MODEL: 1640, S/N: 1-8704088, NEW: 1987
SWING OVER BED ......................... 16"
SWING OVER SADDLE ...................... 9.3"
SWING IN GAP ........................... 24"
DISTANCE BETWEEN CENTERS ............... 40"
HOLE THROUGH SPINDLE ................... 2.04"
SPINDLE NOSE, CAMLOCK, SIZE ............ D1-6"
SPINDLE SPEED RANGE(12) ................ 23 - 1,800 R.P.M.
LONGITUDINAL FEED RANGE ................ .0014 - .0201 IPR
CROSS FEED RANGE ....................... .0004 - .0064 IPR
INCH (32) ........................ 4 TO 56 T.P.I.
METRIC (21) ...................... .5 TO 7 MM
TAILSTOCK SPINDLE DIAMETER ............. 2.2"
TAILSTOCK SPINDLE TAPER ................ #4MT
TAILSTOCK SPINDLE TRAVEL ............... 5"
APPROXIMATE FLOOR SPACE ................ 86" X 36"
APPROXIMATE WEIGHT ..................... 4,000 LBS.
- INCH/METRIC THREADING CAPABILITY
- LEVER-TYPE 5C COLLET CLOSER WITH NOSE PIECE
- ALORIS QUICK CHANGE TOOLPOST
- FOOT TREADLE OPERATED SPINDLE BRAKE
- THREADING DIAL- SELF-CONTAINED COOLANT SYSTEM
- 5 HORSE POWER MAIN DRIVE MOTOR
