Microchip PIC16F877 8-bit cmos flash controller 110 pcs
Model: PIC16F877 8-Bit CMOS FLASH CONTROLLER
Only 35 single word instructions to learn
All single cycle instructions except for program branches which are two cycle
Operating speed: DC - 20 MHz clock input DC - 200 ns instruction cycle
Up to 8K x 14 words of FLASH Program Memory
Pinout compatible to the PIC16C73B/74B/76/77
Interrupt capability (up to 14 sources)
Eight level deep hardware stack
Direct, indirect and relative addressing modes
Power-up Timer (PWRT) and Oscillator Start-up Timer (OST)
Watchdog Timer (WDT) with its own on-chip RC oscillator for reliable operation
Low power, high speed CMOS FLASH/EEPROM technology
In-Circuit Serial Programming (ICSP) via two pins
Single 5V In-Circuit Serial Programming capability
In-Circuit Debugging via two pins
Processor read/write access to program memory
Wide operating voltage range: 2.0V to 5.5V
High Sink/Source Current: 25 mA
Commercial, Industrial and Extended temperature ranges
< 1 ?A typical standby current
