> Agilent hp E4916A crystal impedance lcr meter w/ option
Agilent hp E4916A crystal impedance lcr meter w/ option
HP/Agilent E4916A Crystal Impedance / LCR Meter
This unit is used but has been pulled from a clean, working environment and is in excellent condition! It has been checked for functionality and also passes the system self-test. The unit has very little wear on the physical unit itself, as I would rate the cosmetic condition as 9/10.
Comes with option 010 - LCR Measurement feature
This unit comes with power cord. The manual can be obtained online from Agilent's website.
The HP E4916A is a crystal impedance meter based on the transmission p network method which enables you to:
* Test at high frequencies (1 MHz to 180 MHz)
* Apply low drive level (0.1 nW to 1 mW, when testing a 25 W DUT with the p circuit)
The HP E4916A yet provides a cost effective solution, comparable enough to conventional CI meters.
Specifications of the HP E4916A include:
* Measurement parameters: Fr, Fs, Fa, FL, CI, Q, C0, C1, L1, R1, R0, G0, spurious, DLD, EM, filter bandwidth (Note that Fr and Fs represent the frequencies at which the phase is 0 degree and the maximum conductance is attained, respectively. You can also set up the HP E4916A to search for Fr at which |Z| is minimal.)
* Output Frequency range: 1 MHz to 180 MHz/ 1 mHz resolution
* Frequency accuracy: 2 ppm (can be improved up to 0.2 ppm through external reference input)
* Measurement range: 1 MHz to 180 MHz/1 mHz resolution
* Impedance: 5 to 125 W/10 mW resolution
* Damage level: 25 Vdc, 20 dBm
* Average noise level: -130 dBm/Hz
