New moxa awk-3121-us AWK3121 access point bridge client
AWK-3121 Access Point/Bridge/AP Client
WLAN Standards - IEEE 802.11a/g/b for Wireless LAN, IEEE 802.3u 10/100BaseT(X) for Ethernet LAN, IEEE 802.3af for Power-over-Ethernet, IEEE 802.1D/w STP/RSTP; Frequency Range - 802.11b: DBPSK, DQPSK, CCK; 802.11g: OFDM with BPSK, QPSK, 16QAM, 64QAM; 802.11a: OFDM with BPSK, QPSK, 16QAM, 64QAM; Operating Channels - US: 2.412 to 2.462 GHz (11 channels), 5.15 to 5.25 GHz (4 channels), EU: 2.412 to 2.472 GHz (13 channels), 5.15 to 5.25 GHz (4 channels), JP: 2.412 to 2.472 GHz (13 channels, OFDM), 2.412 to 2.484 GHz (14 channels, CCK), 5.15 to 5.25 GHz (4 channels for W52), Security - 64-bit and 128-bit WEP encryption, WPA /WPA2 (IEEE 802.1X/ RADIUS, TKIP and AES), Data Rates - 802.11b: 1, 2, 5.5, 11 Mbps, 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps; Transmit Power - 802.11b: 1 to 11 Mbps: Typ. 18 1.5 dBm; 802.11g: 6 to 24 Mbps: Typ. 18 1.5 dBm, 36 to 48 Mbps: Typ. 16 1.5 dBm, 54 Mbps: Typ. 15 1.5 dBm; 802.11a: 6 to 24 Mbps: Typ. 16 1.5 dBm 36 to 48 Mbps: Typ. 14 1.5 dBm, 54 Mbps: Typ. 13 1.5 dBm 17dBm; Receiver Sensitivity - 802.11b: -92 dBm @ 1 Mbps, -90 dBm @ 2 Mbps, -88 dBm @ 5.5 Mbps, -84dBm @ 11 Mbps; 802.11g: -87 dBm @ 6 Mbps, -86 dBm @ 9 Mbps, -85 dBm @ 12 Mbps, -82dBm @ 18 Mbps, -80 dBm @ 24 Mbps, -76 dBm @ 36 Mbps, -72dBm @ 48 Mbps, -70 dBm @ 54 Mbps; 802.11a: -87 dBm @ 6 Mbps, -86 dBm @ 9 Mbps, -85 dBm @ 12 Mbps, -82dBm @ 18 Mbps, -80 dBm @ 24 Mbps, -76 dBm @ 36 Mbps, -72dBm @ 48 Mbps, -70 dBm @ 54 Mbps. Antenna - 2dBi dual-band, Omni-directional antenna, Antenna Connector - RP-SMA (female), Connection - 10-pin Removable Terminal Block, Alarm Contact - 1 relay output (capacity: 1A @24VDC), Digital Input - 2 electrically-isolated inputs, Console - RS-232 (RJ45 type), LAN Port - 10/100BaseT(X) auto negotiation speed, Input Voltage - 12 to 48 VDC, redundant dual DC power inputs or 48 VDC Power-over-Ethernet (IEEE 802.3af), Input Current - 0.494 to 0.121 A, Input Current (@ 24VDC) - 0.3 A, Overload Current Protection - 1.6 A, Reverse Polarity Protection, Dimensions - 53.6 x 135 x 105 mm (2.11 x 5.31 x 4.13 in), Weight - 850 g, Installation - DIN-rail, or Wall Mounting (with optional wall mounting kit), Casing - IP30 protection, aluminum case; Operating Temperature: Standard models: 0 to 60 C (32 to 140 F), Wide Temp Models: -40 to 75 C (-40 to 167 F).
The AWK-3121 Access Point/Bridge and AP Client is ideal for applications that are hard to wire, too expensive to wire, or use mobile equipment that connects to a TCP/IP network. The AWK-3121 can operate at temperatures ranging from 0 to 60 C for standard models and -40 to 75 C for extended temperature models, and is rugged enough for any harsh industrial environment. Installation is easy, with either DIN-Rail mounting or wall mounting in distribution boxes. The DIN-rail/wall mounting ability, wide operating temperature range, and IP30 housing with LED indicators make the AWK-3121 a convenient yet reliable solution for any industrial wireless application.
One New Moxa AWK-3121-US, AWK-3121 Access Point/Bridge/AP Client.
