2005 - 70/110 ton scotchman dual operator ironworker
2005 - 70/110 TON SCOTCHMAN DUAL OPERATOR IRONWORKER
70/110 TON SCOTCHMAN DUAL OPERATOR IRONWORKER
MODEL DO 70/110-24M S/N 1293M1005 NEW 2005
Dual Operator allows for Two Operators to Work at the Same Time at
70 Ton Punch Station (1-1/8" in 3/4")
Punch Gauging Table with Fence and Scale
Die Holder Complete with 2" Die Insert
Adjustable Swing-Away Stripper
One Round Punch & Die: Max. Dia. 1-1/4"
Two Adjustable Electric Stroke Controls with Scale
Two Electric Remote Foot Pedals
Rectangle Notcher 3" x 5" x 3/8" & 3" x 4" x 1/2'
110 Ton, 24" Bar Shear with Sabre Blade (1" x 6", 3/8" x 24")
Electrical Box Supplied with Emergency Palm Button and Lock-out Tag
All Guards Necessary to Comply with ANSI B 11-5 Standards
Rated On: 65,000 PSI Tensile - A 36 Mild Steel
Punching Capacity: 70 Ton, 1-1/8 in 3/4"
Flat Bar Shear (Sabre Blade - Std): 110 Ton, 24 Length,
1" x 6", 3/4" x 10", 1/2" x 14", 3/8" x24"
Angle Shear 90 Degrees: 6 x 6 x 1/2
Angle Shear 45 Degrees: 3 x 3 x 3/8
Angle Shear 45 Degrees (with Bar Shear): 4" x 4" x 1/2"
Open End Brake: Max 1/4" x 6" Flat or Angle Iron
Pipe Notcher Schedule 40 ID: , 1 , 1-1/4 , 1-1/2 , 2
Rectangle Notcher: 2 x 2-1/2" x 3/8
90 Deg. V. Notcher: 6 x 6 x 5/16
Notcher Rectangle: 3" x 5" x 3/8", 3" x 4" x 1/2"
Notching in Leg of Channel: 6" to 10"
Round Rod: 1/4" TO 1-1/4", 9 Cav.
Square Rod: 1/4" to 1", 1 Cav.
Square Tube Shear: to 2 , 14 ga.
Offset Die Holder: Max. 40 Ton
SPM - Light Material: Stroke
SPM - Heavy Material: Stroke
Motor Standard: 10 hp, 3 ph, 230/460/208/380/575
Dimensions: 30 W x 65 L x 72-1/8 H
