Milford multihead. 56 riviter automated assembly 9''
Milford Multihead. 56 riviter automated assembly 9''
Milford Multihead. 56 riveter automated assembly 9''
Brand(s):Milford Rivet & Machine Co.
Riveting machine with 3 Milford #56 riveters mounted on 1 muliple head unit.
* Capacity: Up to .125" (3.17 mm) diameter x .562" (14.28 mm) long, mild steel semi-tubular rivets
* Throat depth: 9.00" (228.6 mm)
* Hopper type: 5.25??? dia. mechanical
* Ram stroke: 2.00" (50.8 mm)
* Machine cycle time: 0.75 second
* Overall height: 25.75" (654 mm)
* Footprint: 4" x 20" (102 mm x 508 mm)
See pics for type of rivets used and for physical condition.
