Polyphaser das-tp-001 surge / lightning protector
POLYPHASER DAS-TP-001 Surge / Lightning Protector
POLYPHASER DAS-TP-001 Surge / Lightning Protector for AISG Based Systems
Power line insertion Resistance: 0.5 ohm (max)
Data/Signal line insertion Resistance: 1.0 ohm (max)
Overcurrent Protection: PTC fuse
SPD type: 7 x bipolar gas tubes, Sidactors and PTC fuse
Max Operating Current: 4 A (@ 50 C)
Max Impulse Current: 25kA (Housing), Inner Conductors: 2.5kA/pin (30/350us)
Max dynamic Overvoltage (1kV/us): <700 V
Static Overvoltage (100 V/s): <100 V
Dim: 4.5"x2.5" (including mounting bracket)
Connectors: AISG male and female
