11.81" Swg Nakamura-Tome TMC-15 CNC LATHE, Fanuc 18T, 6
11.81" Swing Nakamura-Tome TMC-15 CNC LATHE, Fanuc 18T, 6" Chk, Chip Conveyor
NAKAMURA 2-AXIS CNC TURNING CENTER
ROUND COLLET CAPACITY...................... 1.34"
CHUCK DIAMETER............................. 6"
SWING OVER BED............................. 11.81"
SWING OVER SADDLE.......................... 6.69"
MAX. TURNING DIAMETER...................... 7.09"
MAX. TURNING LENGTH........................ 9.84"
DRIVE MOTOR................................ AC 7.5 KW/10 HP
SPEED RANGE................................ 135-4500 RPM
SPINDLE NOSE............................... A2-5
HOLE THRU SPINDLE.......................... 1.85"
HOLE THRU DRAW TUBE........................ 1.38"
SLIDE TRAVEL X-AXIS........................ 4.33"
SLIDE TRAVEL Z-AXIS........................ 10.63"
RAPID TRAVERSE X-AXIS...................... 472 IPM
RAPID TRAVERSE Z-AXIS...................... 945 IPM
APPROX. DIMENSIONS......................... 81"Lx50"Wx61"H
APPROX. WEIGHT............................. 5,060 LBS.
