Jet/asian 20 variable speed drill press jdp-20VS manual
20-inch Variable Speed Drill Press JDP-20VS
This is a reproduction, not a photocopy, of an original JET JDP-20VS 20-inch Variable Speed Drill Press Instructions and Parts Manual. This manual contains general safety instructions, operation instructions, assembly instructions, adjustments, maintenance, and a complete set of exploded view diagrams of the parts with description.
SPECIFICATIONS: JDP-20VS-1 JDP-20VS-3
STOCK NUMBER.................................354201...................354203
CAST IRON....................................1-1/2"...................1-1/2"
STEEL........................................1-1/4"...................1-1/4"
TAPPING CAPACITY.............................-...................3/4"
COLUMN DIAMETER..............................4".......................4"
MAXIMUM DISTANCE SPINDLE TO COLUMN...........10"......................10"
SPINDLE TRAVEL...............................6-1/2"...................6-1/2"
SPINDLE DISTANCE TO BASE.....................39"......................39"
SPINDLE DISTANCE TO TABLE....................28-1/2"..................28-1/2"
TABLE SIZE...................................22"xl9-l/2"..............22x19-1/2"
NUMBER OF T-SLOTS............................2........................2
T-SLOT SIZE..................................5/8".....................5/8"
CENTERS......................................8-7/8"...................8-7/8"
SPINDLE TAPER................................MT-3.....................MT-3
SPINDLE SPEEDS...............................VARIABLE.................VARIABLE
SPINDLE RPM..................................300-2,000................300-2,000
MOTOR........................................1-1/2 HP,1 Ph............2 HP,3 Ph
.............................................115/230V.................2-SPEED
.............................................PREWIRED 115V............220V ONLY
OVERALL HEIGHT...............................69"......................69"
BASE SIZE....................................26"xl9"..................26"xl9"
TABLE TRAVEL.................................20"......................20"
NET WEIGHT (APPROX.).........................720 LBS..................740 LBS.
