Instek GDS2064 digital oscilloscope 60MHZ, digital dso
* Free 128 MB USB Storage Device
* Free Remote Control Software ( program the unit, download data, download images, etc )
* 1GS/s Real-Time and 25GS/s equivalent-Time Sampling
* 25K Points Record Length Maximum
* Large 5.6-in TFT Color Display
* USB Host/Device: Support USB Printer and USB Flash disk. Use a USB thumb drive to store data, images, settings, and even do firmware updates via the USB.
* DC Battery Power Operation (optional)
* Up to 24 Automatic Measurements
* Video/Pulse Width/Event-Delay/Time-Delay Trigger
* Program Mode and Go-No Go Function
* Multi-Language and Build-in On-Line Help
* A Large 8 12 Divisions Waveform Display
* Ultra-bright color TFT display - Wide-angle viewable area
* Store waveform raw data (CSV files)
* Capture screen image as BMP files
* Print waveform via USB printer
* Better Performance - Faster Sampling Rate, Longer Memory & Advanced Trigger
* More Features - Auto Frequency Counter, Auto Setup Sequence, GO/NO GO, 12 Div Display, Simultaneous Cursors
* More Value Added Features - RS-232C (Std.), USB Host/Device (Std.), GPIB IEEE 488.2 (Opt.), Free Software
* Valued Plus Features - Real Time Frequency, Counter, Auto Setup Sequence, Multi-Language, Built-in Help Menu
The GDS-2000 Series Digital Storage Oscilloscopes feature a bandwidth of 60, 100 or 200MHz. These 2 or 4 channel instruments deliver a sample rate of 1G Samples/s and a maximum record length of 25K Samples. The scopes can be programmed to take up to 24 different measurements automatically and results can be displayed on the large 5.6 inch color TFT display. A Go/ No Go mode is particularly useful in a production set-up. USB host and device interfaces are provided as standard, with GPIB as an option.
USB Host/Device: Support USB Printer and USB Flash disk. Use a USB thumb drive to store data, images, settings, and even do firmware updates via the USB.
Digital Osilloscope - 60MHz, 1GS/s, 4 Ch. with RS-232, USB.
Digital Osilloscope - 60MHz, 1GS/s, 2 Ch. with RS-232, USB.
Digital Osilloscope - 100MHz, 1GS/s, 4 Ch. with RS-232, USB.
Digital Osilloscope - 200MHz, 1GS/s, 2 Ch. with RS-232, USB.
Digital Osilloscope - 100MHz, 1GS/s, 2 Ch. with RS-232, USB.
Digital Osilloscope - 200MHz, 1GS/s, 4 Ch. with RS-232, USB.
GPIB Option for GDS 1000/2000 Series ( can be user installed)
Battery Option for GDS 1000/2000 Series (FACTORY INSTALL ONLY)
RS-232 Cable for GDS,GRS,SFG,LCR,PSM
USB Cable, USB 1.1 A-B TYPE CABLE, 4P, 1800mm
Up to 24 Automatic Measurement Functions:
Vhi, Vlo, Vmax, Vmin, Vp-p, Vavg, Vrms, Vamp, Rise Time , Fall Time, Width+ , Width-, Period , Duty cycle, Frequency, Delay
Enable user to switch from time domain to frequency domain!
Useful math function for school education
Simultaneous Horizontal Cursors ?V and Vertical Cursors ?T
Adjustable Probe Compensation Signal
USB 1.1 & 2.0 device & host supported
Real time Video display on PC Monitor through USB.
Captured Waveform Data transferred to PC through USB/RS-232C/GPIB.
