Mastech MS8222H digital multimeters
MASTECH MS8222H DIGITAL MULTIMETERS
Display 1999 counts and 40 segments bar graph
DC Voltage: 200mV / 2V / 20V / 200V 0.5%, 1000V 0.8%
AC Voltage: 200mV / 2V / 20V / 200V 1.0%, 700V 1.2%
DC Current: 2mA / 20mA 1.0%, 200mA 1.5%, 10A 2.0%
AC Current: 2mA / 20mA 1.2%, 200mA 2.0%, 10A 3.0%
Resistance: 200 / 2k / 20k / 200k / 2M / 20M 1.0%
Capacitance: 2nF / 20nF / 200nF / 2 F / 20 F 4.0%
Inductancy: 2mH / 20mH / 200mH / 20H 3.0%
