Mitsui high-tec #msg-200MH manual surface grinder
MITSUI HIGH-TEC #MSG-200MH MANUAL SURFACE GRINDER
Made in Japan by Mitsui High-Tec Inc.This is a Manual Surface Grinder in working condition.Model #: MSG-200MHSerial #: 92057738
* Construction - Extremely heavy meahanite castings, internal rib reinforced. Our meahanite casting base uses jack bolts and plates for a 3 point leveling system. Another feature, which is a trademark with the Mitsui Design, is the ease in removal and replacement of key components, providing for "No Hassle" maintenance which translates to minimum down time and cost.
* Precision - Not all surface grinder manufacturers can attest to precision the way we do. Our cartridge spindle is second to none and REMOVABLE. The carriage/saddle moving on (2) 45 "Vees" combined with the table moving on Linear Ball Bearings make for the repeatability for which MITSUI is known. NO design compromises here.
* Durability - Precision by design means little if it can not be maintained. MITSUI provides the durability for this with D-2 hardened and ground steel ways on the table, Carriage/Saddle and even on the column for vertical movement. The linear ball bearings complement the table/carriage union with durability. The cartridge spindle's lubrication is sealed in for life and the dust sealed out. The Standard Automatic Lubricating System leaves you 1 less task to worry about, as it lubricates ALL vital components automatically to insure minimal wear and friction.
* Walker #LBP 12" x 6" Electromagnetic Chuck.
* Mitutoyo #AL-321L 2-Axis DRO (Y & Z Axes).
Magnetic Chuck Size: 12" x 6"Travels:
Longitudinal Travel (X-Axis): 15"
Cross Feed Travel (Y-Axis): 8"
Vertical Wheelhead Travel (Z-Axis): 15"Wheelhead:
Grinding Wheel: 8" x 3/4" x 1-1/4"
Maximum Distance From Table to Spindle Center: 18"General:
Motor: 1 kW, 3,490 rpm, 460 Volt, 1.62 Amps, 60 Hz
Electrical: 460 Volt, Three Phase
Overall Dimensions: 46" x 46" x 72" tallComes as shown in pictures.
