12" w 40" l birmingham wsg-1240AHD 3 axis automatic sur
12" W 40" L Birmingham WSG-1240AHD 3 Axis Automatic SUR
12" Width 40" Length Birmingham WSG-1240AHD 3 Axis Automatic SURFACE GRINDER, Magnetic Chuck Include
New "BIRMINGHAM" PRECISION 3-AXIS AUTOMATIC
- Column: enlarged, double wall, strongly ribbed column,
especially suitable for heavy duty grinding
- Construction: construction of table, saddle and base is casted
with high grade casting iron, strongly ribbed
- Spindle: Enlarged spindle set is supported by 4 pieces of
preloaded precision angular contact ball bearings for heavy
- Slideways: Vertical, cross (double vees) and logitudinal (one vee
& one flat) slideways are coated with Turcite-B,
provides stable movement and durable accuracy.
- Automatic Continous Lubrication System: All slideways and
screws are fully oiled by automatic continuous lubrication
system to eliminate wears on slideways & screws.
- Hydraulic Table: table speed ranges 5-25m/min. with rack and
pinion table drive for hand operation
- Proximity Switch: provide built-in-type (hidden) proximity
switch, features safe and easy operation
- Table Speed Control: Presettable hydraulic table speed control
allows operator to pre-set speed rate, enable to get
same speed rate when engaging hydraulic table every time
- Hand Wheels: zero-setting slip-rings with vernier on vertical
handwheel, and vernier on crossfeed handwheel
Max. distance from spindle center to table: 23"
Magnetic chuck size: 11.8" x 39.4"
Speed of table longitudinal movement (in/min): 280" - 1000"
Auto Feed(in/min): 0.004" x 0.3"
Feed of Handwheel(in/div): 0.0008"
Auto Feed(in/stroke): 0.0002" - 0.002"
Feed of Handwheel(in/div): 0.0002"
(OD x W x ID) Size: 13.8" x 1.6" x 5"
Max. loading capacity of table (include magnetic chuck): 900 lbs.
Overall dimension (L x W x H): 125" x 88" x 74.4"
- Standard permanent magnetic chuck
