New load cell 35 kg
Great for scales and for commercial, industrial and experimental purpose.
Elane Load Cells are economical and highly accurate. The quality is the same as "famous maker's" items
For over 20 years, we have manufactured load cells for our own scales and supplied large quantities of standard or custom made load cells internationally for other businesses and scale manufacturers.
Our Store also has many other load cells to choose from
15kg(30lb); 30kg(60lb);35kg(70lb)
0.03 %F.S. ( within 5 minutes)
0.030~0.05 %F.S. ( within 5 minutes)
NONLINEARITY ,HYSTERESIS AND REPEATABILITY
TEMPERATURE EFFECT ON OUTPUT %OF APPLIED LOAD
TEMPERATURE EFFECT ON ZERO %OF RATED OUTPUT
(Red: +Excitation; Black:-Excitation
Green: +Signal; White: -Signal)
4 leads, flexible stranded wire length 200 mm , PVC insulated AWG 28, UL listed
Offers high accuracy and excellent linearity.
Our email support is located in a different time Zone (Asia) - but we answer every email received from Monday to Friday GMT+6 - so please do not hesitate to ask questions or request a datasheet.
