1985 landis 18" x 48" model 3RH universal id/od grinder
1985 LANDIS 18" x 48" MODEL 3RH UNIVERSAL ID/OD GRINDER
18" X 48" LANDIS "PRECISION" (MADE IN THE USA)
MODEL: 3RH S/N: 891-29 NEW: JULY 1985
NOMINAL SWING ............................. 18- 31/32"
DISTANCE BETWEEN CENTERS .................. 48"
HYDRAULICALLY POWERED TABLE TRAVERSE ..... 2" TO 240" IPM
TRAVERSE PER TURN OF HANDWHEEL, SLOW ...... 0.100"
SWIVEL TABLE GRADUATED, IN. PER FT. ....... 4- 1/4"
DEGREES INCLUDED ANGLE ........ 19 DEG.
FINE FEED ADJUSTMENT IN INCREMENTS OF ..... 0.000025"
WORK DIA. REDUCTION PER REV. OF
HANDWHEEL ................................ 0.100"
WORK DIA. REDUCTION PER REV. OF FINE
FEED KNOB ................................ 0.005"
GRINDING WHEEL............................. 14" X 2" X 5"
GRINDING WHEEL SPINDLE SPEEDS .......... INFINITELY VARIABLE
SWIVEL RANGE-UPPER......................... 180 DEGREES
SWIVEL RANGE-LOWER......................... 60 DEGREES CW
INFINITELY VARIABLE WORKHEAD SPINDLE
SPEEDS, LOW RANGE ........................ 12 TO 72 RPM
HIGH RANGE ....................... 60 TO 360 RPM
HEADSTOCK SPINDLE HOLE (DIAMETER).......... 1-7/16"
HEADSTOCK SWIVEL RANGE..................... 120 DEGREES
HEADSTOCK SPINDLE NOSE..................... 6A-2
HEADSTOCK WORK CENTER ..................... #14 JARNO
TAILSTOCK WORK CENTER ..................... #10 JARNO
APPROX. FLOOR SPACE REQUIRED FOR OPERATION .. 74" X 169"
APPROX. WEIGHT .............................. 11,200 LBS
DOUBLE SWIVEL WHEELHEAD DESIGN
WHEEL CAN BE MOUNTED ON EITHER THE LEFT SIDE OR RIGHT SIDE
AUTOMATIC INFEED OF WHEELHEAD @ TABLE REVERSAL
ADJUSTABLE TABLE TARRY (L.H. & R.H.)
INFINITELY VARIABLE WORKHEAD SPINDLE SPEEDS
DUAL LIVE/DEAD WORKHEAD SPINDLE
TAILSTOCK CENTER MOVEMENT BY LEVER & HANDWHEEL
LANDIS "MICROSPHERE" WHEEL SPINDLE BEARINGS
SELF-CONTAINED HYDRAULIC SYSTEM
15 H.P./3/60/230-460 VOLT WHEELHEAD MOTOR
SWING DOWN I.D. ATTACHMENT w/SPINDLE
VERY LATE MODEL "CUTLER HAMMER" ELECTRONIC DRIVE
PROVIDING INFINITELY VARIABLE SPINDLE SPEEDS FOR THE
WHEELHEAD. DIGITAL DISPLAY OF THE WHEEL SPEED IS
LOCATED JUST ABOVE THE WHEELHEAD.
"VEE ARC" ELECTRONIC DRIVE PROVIDING INFINITELY VARIABLE
SPINDLE SPEEDS FOR THE WORKHEAD.
"VOLKMANN" ELECTRONIC VARIABLE SPEED DRIVE FOR THE I.D.
POWER RAPID WHEELHEAD POSITIONING IN & OUT BY A PUSHBUTTON
4-JAW CHUCK MOUNTED ON WORKHEAD
SELF-CONTAINED COOLANT SYSTEM IN THE BASE
* EXCELLENT CONDITION & APPEARANCE *
Click Here For More Landis Machines
