White-rodgers 1F82-0261 programmable (5+1+1 day) heat
Condition: New White-Rodgers 1F82-0261 Programmable (5+1+1 day) Heat Pump Thermostat
White-Rodgers 1F82-0261 Programmable (5+1+1 day) Heat Pump Digital Thermostat uses the technology of a solid-state microcomputer to provide precise time/temperature control, as well as offer you the flexibility to design heating and cooling programs that fit your needs.Replaces 1F82-261.
* 4 time and 4 temperature settings per program (heat & cool)
* Patented pre-programmed software simplifies time and temperature programming
* Easy-to-read LCD with improved contrast
* Lighted display for easier low-light viewing
* Permanent program retention during power loss
* Simple setup menu to activate optional features
* Temporary temperature override two-hour minimum or until next program period
* Display temperature recalibration (+/- 4 )
* Dual-Powered choice of battery-powered or hardwired, for all applications
* Selectable Energy Management Recovery
* Meets ENERGY STAR specifications
* Meets California Building Code, Title 24
* Fast (FA) or slow (SL) heating cycle anticipation
* Easy-to-wire push-connect color coded terminals
* Compressor lockout protection
Dual Power or Battery Power Model . . . . mV to 30 VAC, NEC Class II, 50/60 Hz or DC
Input-Hardwire Model . . . . . . . . . . . . . . . . 20 to 30 VAC
Terminal Load . . . . . . . . . . . . . . . . . . . . . . . 1.0 A per terminal,
1.5A maximum all terminals combined
Setpoint Temperature Range . . . . . . . . . . . 45 to 90 F (7 to 32 C)
Anticipation, Heating . . . . . . . . . . . . . . . . . . Adjustable
Anticipation, Cooling . . . . . . . . . . . . . . . . . . Fixed
Rated Differential, Heat . . . . . . . . . . . . . . . 0.8 or 1.2 F
Rated Differential, Cool . . . . . . . . . . . . . . . . 1.2 F
Operating Ambient Temperature Range . . . 32 to 105 F (0 to 44 C)
Operating Humidity Range . . . . . . . . . . . . . 0-90% RH noncondensing
Dimensions . . . . . . . . . . . . . . . . . . .3-3/4 H x 4-3/4 W x 1-1/2 D
Terminals: R, C, Y, W2, G, O/B, L
