Pall filtron centrasette 5 lab filtering system
PALL FILTRON CENTRASETTE 5 LAB FILTERING SYSTEM
Here is a PALL FILTRON CENTRASETTE 5 FILTER SYSTEM , just in from a local lab's surplus.
The Centrasette 5 holder is intended for use in pilot and process scale applications with up to 5 m2 (54 ft2) screen channel Centrasette or Centrasette II cassettes or 4 m2 (43 ft2) of suspended screen cassettes. The feed/retentate channels have tapered bores engineered to maintain uniform cross flow and pressure drops across the membrane cassettes. Two permeate ports, one near the feed and the other near the retentate, are designed to reduce backpressure on the permeate side of the membrane. This is especially important when operating at high flux rates. Pressure on the permeate side effectively reduces transmembrane pressure and lowers filtrate flux rates. The highly polished 316L stainless steel unit has ports that mate up with 1 in. sanitary connectors. A calibrated torque wrench and socket is supplied with the holder, as it is with other manual torque holders.
The following tables list cassette holders with relative area capacities (screen channel cassettes) and working volumes1.
MEMBRANE AREA (nominal m2): 0.46 - 4.6 m2
MEMBRANE AREA (nominal ft2): 5 - 550 ft 2
WORKING VOLUME START 2: 2.5 - 1,000 L
WORKING VOLUME FINAL 2: 1,000 mL
For additional information go to: http:// /biopharm_33940.asp
