Hp 8556A spectrum analyzer rf section for hp 141T
20 Hz - 300 kHz RF Spectrum Analyzer
The Agilent/Hewlett-Packard Model 8556A Spectrum Analyzer covers the frequency range from 20 Hz to 300 kHz. When it is combined with a IF section and a Display Section it functions as the tuning section of a low frequency spectrum analyzer
The analyzer electronically scans input signals and displays their frequency and amplitude on a CRT. The horizontal, x-axis, is calibrated in units of frequency and the vertical, y-axis is calibrated in absolute units of voltage ( V, mV, dBV) or power (dBm). Therefore, absolute and relative measurements of both amplitude and frequency can be made
* Synthesized / Non Synthesized: Non-Synthesized
Click here for complete specifications
