Thermostat, refrigeration, bi-metal, derwent R53000002
REFRIGERATION THERMOSTAT, BI-METAL DERWENT R53000002
Operating temperature 24 degC; differential 19 degC;
Model T3A auto-reset R53000002
Fitted with two RADOX125-insulated leads, 1.5mm2, 300mm long:
one white and one white with red stripe; each with boot-lace terminals
* Fully encapsulated in epoxy resin for moisture protection
* They have been tested and certified for 250 VAC with 25A current rating - not to just 10A like the cheap equivalent imported thermostats
* No exposed terminals. Connections are made with insulated flexible connecting leads
* Provide heavy-duty thermal protection (insensitive to current). Temperature sensing is achieved by surface-to-surface contact, such as attaching the front face of the protector onto a flat surface to be monitored
* In order to sense temperature from a pipe, a range of thermostat front faces with different radii are available to suit this method of fixture
