Case portable steam engine 3 inch scale model


Case Portable Steam Engine 3 inch Scale Model
3 Inch Scale Model Steam Portable. Weighing around 450 lbs. and measuring 52" long x 22" wide x 49" top of stack. Cast Iron castings on the engine and cross slide. Also included is a 7-inch diameter by 1-inch steel crank disk, bronze eccentric, cast iron piston and rings, and all moving parts for the engine. The engine will run on 20 lbs. of steam or air pressure. The bore is 3 inches with a 4-inch stroke. It also features a 12" diameter x 52" boiler that is 3/8-inch thick with a Penberthy injector, a oiler for the engine, and a pop off valve set at 100 lbs.
You can see this engine running on youtube. Here is the link:
http:// /watch?v=vhHyTiNidwg
The boiler has a waterleg. There is a 1" space between inside of the boiler shell and the outside of the firebox.
The tubes are made of 1"x .065 steel boiler tube that are welded in and are 24" long.
I will build a wood crate on a pallet and deliver it to a freight terminal in Seattle.
The last photo shows a 4 1/2 x 1 inch diameter oiler that I just comleted and installed.
