Hi performance 6 element yagi beam antenna - cb
HI PERFORMANCE 6 ELEMENT YAGI BEAM ANTENNA - CB HAM
AS-611HP BY ARRAY SOLUTIONS - THE BIG TALK ON CHANNEL 6 !!
TRANSFORMS 100 WATTS INTO 5000 WATTS EFFECTIVE TRANSMITTING POWER
YOU WILL SPEND 3 TIMES THIS AMOUNT FOR AN ILLEGAL AMPLIFIER TO EQUAL THE EFFECTIVE OUTPUT POWER THIS ANTENNA GIVES YOU !!
BE SURE AND LOOK FOR OUR AD IN JANUARY ISSUE OF POPULAR COMMUNICATIONS
Do you want to be top dog on the band ? Then this antenna is for you. This is a professional grade high performance yagi beam designed for maximum transmitting gain using a direct-to-driven element balanced 50 ohm feed point thus eliminating failure-prone gamma matches and hairpins. The antenna is also designed to cover the entire band with very little degradation to SWR and pattern. The elements of the antenna are made with large diameter aluminum tubing with corona eliminating end pieces and special insulators that allows the antenna to handle power up to 10,000 watts.
The antenna is an OWA design ( Optimum Wideband Antenna ) which is becoming very popular with ham radio operators requiring superb gain characteristics.
The antenna requires a 50-ohm Balun at the feedpoint. I can supply this for an additional $125.00.
The antennas are manufactured and professionally boxed upon point of sale. All hardware for proper assembly are included.
* Frequency coverage: 26.75 to 27.75 mhz
* SWR less than 1.2:1 across entire frequency coverage
* Front to Back ratio: > 20db
* Front to side ratio: > 30db
MECHANICAL SPECIFICATIONS * Boom length: 40 feet
* Longest element: approximately 18 feet
* Wind load: 5.5 sq feet area
