Wireless pipe borescope recordable inspection camera
High resolution remote color camera
Autofocus (Viewing distance: 2" and up)
3.5" full color viewing monitor
3/4 inch shaft diameter at tip
Shaft material: High-density polyethylene (HDPE)
3 ft standard shaft length (Can be up to 9 feet, if you want to order the additional shaft, please contact us.)
4 hrs operation on 4 AA batteries
Mirror, hook and magnet accessories included
Video out for optional recording
Video out port: Mini jack - NTSC signal
Light source: (2) white LED's in tip
Viewing angle: 50 (without clip-on mirror)
Power: (4) AA batteries for hand held and rechargeable (Included) for Monitor
Battery life: approximately 4 hours
Media type Micro SD card UP to 12 Gig (like commonly used in cell phones)
Output Media is AVI for Videos and Jpg for Snapshots - AVI can normally be played by Windows media player and Jpg is a common file format used and can be viewed in Windows
Software is included for viewing the images. It is packed on a mini disc and is compressed in a RAR file if you want to try to use it. We have not tested it since the file formats are standard.
If you see a bright white screen, you probably have the camera lens right up against a reflective surface that is bouncing the LED light back into the camera, creating glare. Just pull the probe back a bit.
If you are working inside a contained area with little or no ambient light, remember that the Led's are providing the illumination. Moving the camera tip in and out a bit can improve lighting on the object for the best screen display.
When using the mirror for right angle views, clean the mirror glass carefully with a lint-free cloth. Small specks of dirt and dust and fingerprints degrade the screen image.
