22.4" swg 24" cc mori seiki sl-3B cnc lathe, fanuc 6TB,
22.4" Swg 24" cc Mori Seiki SL-3B CNC LATHE, Fanuc 6TB,
22.4" Swing 24" Centers Mori Seiki SL-3B CNC LATHE, Fanuc 6TB, Tailstock, 12' barfeed
SWING OVER BED/FRONT COVER................ 22.4"/15.7"
SWING OVER CARRIAGE/CROSS SLIDE........... 20.1"/13.8"
DISTANCE BETWEEN CENTERS.................. 24.0"
MAX LONGITUDINAL TRAVEL (Z)/WORKS LENGTH.. 22.0"/21.6"
MAXIMUM CROSS TRAVEL (X).................. 6.3"
SPINDLE CENTER HEIGHT FROM FLOOR.......... 44.6"
PROGRAMMABLE SPINDLE SPEED RANGE.......... 30-3000 RPM
SPINDLE NOSE.............................. A2-6"
HOLE THRU SPINDLE......................... 2.36"
SPINDLE INSIDE TAPER...................... MT-7
TAIL STOCK QUILL DIAMETER................. 3.34"
TAIL STOCK QUILL TAPER.................... MT-3
TAIL STOCK QUILL STOCK.................... 3.1"
TURRET TOOL POSITIONS..................... 10 TOOLS
MAIN MOTOR................................ 20 HP
WEIGHT.................................... 9240 LBS.
FANUC 6TB CNC CONTROL W/RS 232 PORT
