> Perkin-elmer ion pump vacuum chamber bell jar system
Perkin-elmer ion pump vacuum chamber bell jar system
#1 Perkin-Elmer Ion Vacuum Pump
*** and NO, ID plate that we could see.
This unit had vacuum on it and was under pressure.
#2 H.V.A. Inc. 8 CFF Gate Valve
*** And is 8 CFF gate to a 8 CFF 4-way
*** dimensions (17 long x 14 high)
*** plus two-2.75 OD-CFF ports
___one capped with a feed through & shut off valve
*** accelerator with ion source, ion probe feed through
#4 Zero Length Adaptor Plate Huntington
*** from 8 CFF to a 14 CFF conflat
#5 Custom Bell Jar with 8 entry Ports:
*** 14 CFF conflat bottom to 10 CFF at the top
*** Which leads to a Huntington Micro-Adjustment PM-600-XYZ-TRC
C. one 6 CFF capped with a 6 CFF that has
___(three-1.25 CFF blanks + one 2.75 CFF)
E. one 8 CFF capped with eight 1.25 blanks
___(some with microwave feed through) and
___one-2.75" CFF feed through, all extended about 8 out from bell
H. Also, with electric charge tape WatLow
___120V@125W a # 8506C 1LT and a
___# 8534C 1LT , all around the unit
#6 Huntington Micro Adjustment unit Model PM-600-XYZ-TRC
*** Lots of feed through ports
*** 4-5 Different Micro Adjustments
The whole vacuum chamber fits on a steel frame that is (28 x 28 x 30 inches high) and is made of (1 X 1 ) square.
All is mounted on a (36 x 36 x 2 inch thick) bottom plate/platform by Micro-g TMC.
Complete height of the whole unit, frame and all ( 62 H @ 33 W ).
This is a real nice piece but has NO power supply and NO Ion Pump Controller available, will need some other adjustment too and maybe even rebuild the Ion Pump.
PS: Please double click scroll down photos to enlarge item for a closer view.(O_1226_f10)
