30 ton 30" thrt whitney, w.a. 635 single sta. punch pre
30 Ton 30" Thrt Whitney, W.A. 635 SINGLE STA. PUNCH PRE
30 Ton 30" Throat Whitney, W.A. 635 SINGLE STA. PUNCH PRESS
W.A. WHITNEY HYDRAULIC SINGLE STATION PUNCH
TONNAGE (NOMINAL RATING) ..................... 30 TONS
THROAT DEPTH W/GAGING ........................ 30"
OPERATING PRESSURE (MAX.) .................... 1500 PSI
DIE HEIGHT FROM FLOOR ........................ 39"
MAX. MATERIAL THICKNESS (STAINLESS) .......... 1/4"
MAX. MATERIAL THICKNESS (WITH OPTIONAL
CLAMP INSERTS & SPECIAL STRIPPER INSERTS) ... 3/8"
TEMPLATE CAPACITY ............................ 30" X 50"
GAGING, FRONT TO BACK ........................ 30"
GAGING, PUNCH CL TO L. & R. .................. 72"
SHUT HEIGHT LESS BOLSTER ..................... 8- 1/2"
OPENING IN BED PRESS (DIA.) .................. 5- 1/4"
OPENING IN DIE SHOE (DIA.) ................... 5- 1/8"
STROKE ADJUSTMENT ............................ 1/4" TO 2"
TABLE ADJUSTMENT VERTICAL (OPTIONAL) ......... 3"
APPROX. DIMENSIONS ...................... 150" X 88" X 69"H
PUNCHING CAPABILITIES IN MILD STEEL:
