100 watt 50 ohm dummy load 1GHZ n female connector 3346
100 Watt 50 Ohm Dummy Load 1GHz N Female Connector 3346
This is a 50 ohm dummy load that can handle 100 Watts of power. It has a N-female connector for attachment to a cable.
We have a variety of these loads, some have the golden color anodized aluminum as shown in the photo, others are black anodized aluminum. We swept a sample of these loads and the photo shows a graph of the typical performance. They are usable to about 1 GHz.
These loads have been tested for the proper impedance.
