Tek DC503 dc-503 dc 503 service & operations manual
Reproduction quality, very high resolution scanned copy on CD-ROM
of the service and operation manual for the
Tektronix DC503 UNIVERSAL COUNTER
(Plug-in for the TM500 / TM5000 series )
P/N 070-1141-01, 91-pages in 32-MB in PDF file format.
Later printing of the manual ( August 1983) covering 12 years of production and a wide range of serial numbers. Serial numbers directly referenced are B010100 THROUGH "B177190 & UP". Includes operating instructions, theory of operation, parts lists, schematics, calibration and service info and more.
* Hyperlinked Table of Contents & Theory of Operation sections.
* Electronic Page numbers = actual page numbers (1-1, 2-3 etc)
