Weston 4" 316 ss filled -30 to 0 psi pressure gauge
WESTON 4" 316 SS FILLED -30 TO 0 PSI PRESSURE GAUGE
Case Diameter Size: 4" (100mm)
Connection: 316 SS, welded 1/2" NPT lower mount + F threaded Snubber insert
Wetted Parts: 316 Stainless Steel
Media Temperature: 212 F maximum
Ambient Temperature: 30 F to 160 F
Suitable for corrosive environments in chemical, petro-chemical, refining, power, marine and food and pharmaceutical processing applications. Features all stainless steel construction.
Gauge can also be liquid filled in the field. Liquid filled pressure gauges provide users with a number of advantages in certain applications. They are ideally suited for uses on equipment where excessive vibration and pulsation are encountered such as pumps, compressors and machine tools etc. The liquid fill minimizes the effect of these severe environments, protects the gauge internals and provides continuous lubrication in the mechanism, all adding up to extended service life. Liquid filling provides greater protection of the gauge internals from corrosive atmospheres. Gauges can be filled with a variety of fluids including glycerin, mineral oil and silicone oil.
Product: -30 TO 0 PSI PRESSURE GUAGE
