Van norman right angle boring mill head 50 taper g&l
Van Norman Right Angle Boring Mill Head 50 taper G&L
This is a Van Norman brand 50 taper right angle boring head in very good condition. A variety of 50 taper holder styles can be held securely in this head by using a standard bolt draw in system. The mounting arbor on the head will fit Van Norman boring mills only. This mounting arbor on the right angle head can be modified or replaced to mount this head to a Giddings & Lewis or other brands of boring mills. Please send us a contact phone number, the model number and brand of machine you want this head to attach to and we will do the research.
Style: 90 degree Right Angle Machining Head
Boring Head Taper: Holds 50 taper tool holders
50 taper face bolt pattern: Has 4 threaded bolt holes, 5/8-11
50 taper slot size: Width: 1.00 , Depth: .500 , Length: 1.250
50 taper face locating pin size: .375 diameter
50 taper bolt draw in size: 1.250
Head Graduations: 0 to 90 degrees then it repeats the 0-90 graduations
Head Over All Length: 15.00
Head Mounting Style: Currently for Van Norman Machines
Mounting Plate Diameter: 7.00
Mounting Plate Face: Equipped with 4 outer slots, .562 width
Mounting Plate Drive Arbor: Head is powered thru 2 slots that are 1 square
Maintenance Procedure: Has grease fittings in strategic locations
Condition of Tool: Very Smooth
This is a very heavy duty right angle head attachment, quality made. Extensions can be made for it. Adapters can be machined to allow this head to fit a variety of machine tools. There is a large selection of 50 taper tooling that will fit this head from many well known manufacturers of tooling.
