> Shrink tunnel heat oven packaging wrapper tun-4525
Shrink tunnel heat oven packaging wrapper tun-4525
NEW IN BOX Falcon Shrink Tunnel
For Wrapping Individual Products or Bundles in Shrink Wrapping Materials
The shrink tunnel TUN-4525 supplies heated air to an enclosed chamber for the purpose of shrinking a polymeric film around a package for physical protection and improve the appearance of containers or products. This tunnel includes an electronically controlled conveyor for carrying packages through the chamber.
* Simple to Use Minimal Operator Training
* High-Density Roll-Type Conveyor
* Conveyor height from floor 32-34 Inches (812 -864 mm)
* Conveyor Speed (0-12 m/min)
* Heat temperature can be controlled from (0 to 200 C).
* Silicone protected conveyor rollers to avoid product damage.
* Heat System on/off Switch.
* Heat System Indicator Light.
* Air System on/off Switch.
* Air System Indicator Light.
* Temperature Controller (0 to 200 C).
* Electronic Conveyor Speed Controller.
* Control Panel Mounted Ammeter. (Shows operating line current)
Conveyor Rollers Length 14 1/2" ( mm)
Rolling casters and adjustable height feet. (Approx. Range: 2 Inch)
Work Efficiency: 2000-3000 Packages Per Hour
Power: 9 KW / Max 30 Amps per LineMax.
Tunnel Path Dimensions: 40 (1016mm) x 10 (254mm) x 18 (457mm)
Machine Dimensions: L 52 (1320mm) x W 28 (711mm) x H 55 (1400mm)
Machine Weight: 584 lbs (266 Kg)
Box Dimensions: L 57 (1450mm) x W 33 (840mm) x H 44 (1120mm)
