Shortwave radio panasonic rf-5000C lw am fm sw bands
Shortwave Radio Panasonic RF-5000C LW AM FM SW Bands
This radio is in nearly new condition - very well kept over the years and fully functional. Rare find in this condtion. Comes with instruction manual and service manual. Just a bit of dust. All dials and buttons work fine.
The Panasonic RF-5000 radio tunes the LW, AM, FM andshortwave bands which are selected by band buttons. This very rare, late production unit has 4 extra buttons for BW, AFC, ANL and BFO. It has an S-Meter, Bass, Treble and Fine Tuning. The protective front cover pulls down to reveal a world map and time zone calculator. The world map slot holds several Utilization Guides. The radio operates on AC from the built-in, multi-voltage power adapter or six D cells (not supplied). The rear panel has extensive antenna inputs. The radio has two built in whip antennas and a loop.
The Panasonic RF-5000 solid-state radio receives the long wave, AM, FM and 8 shortwave bands. Long wave is 100-40 kHz, AM band is 525 to 1605 kHz. FM is from 76-108 MHz. Shortwave coverage is: 1.6-4.5, 4.5-6.5, 6.5-9, 9-12, 12-16, 16-20, 20-25 and 25-30 MHz. This radio features a tone control and electrical fine tuning knob. Bands are selected by a buttons on the top of the radio. There is a tuning meter and a momentary contact lamp switch plus an AFC On/Off switch. The back panel has numerous I/O jacks for: Record Out, Phone Input, MPX Output, and Earphone (mini jack). There are also external antenna jacks. This radio has a dual telescopic whip and a fold-down loop antenna. A full sound is delivered via the 7 x 5 oval and 5 inch round speaker system. Operation is from 117 VAC or six D cells.
