Hp / agilent 6632A power supply 20V/ 5A/100W
HP / AGILENT 6632A POWER SUPPLY 20V/ 5A/100W
Description: The HP Agilent 6632A is a 100W, single output; series pass regulated power supply optimized for systems applications and is fully programmable via HPIB. The HP 6632A allows both the voltage and the current output to be programmed for either CV or CC operation. A built in DVM and precision current shunt measure (read back) the actual power supply output. The HP 6632A not only will source current, but will also sink as well. This provides very fast down programming speeds throughput in production test applications. The negative current setting tracks the user programmed positive current (CC) setting. Remote sense terminals allow for precise voltage regulation at the load. This feature will compensate for load lead IR drops of up to 2 volts per lead. The HP 6632A Power Supply also features overvoltage and overcurrent protection, self test capability, software calibration, Fast and Normal operating modes, and with option 760, Isolation, Polarity Reversal Relay and Discrete Fault Indicator and Remote Inhibit lines along with a quick disconnect DC output terminal connector. Other features and specifications of the HP 6632A Power Supply include:
* Linear output regulation
* Precision low current measurement
* High-speed programming, 2 ms (400 s in fast mode)
* Measured V & I read back over GPIB
* B-Models add RS-232 and rotary knob
