Rockwell overarm router/shaper operating/part manual
This is a reproduction, not a photocopy, of a Rockwell Overarm Router/Shaper Instructions and Parts Manual.This manual contains information on lubrication, adjustments, maintenance, and controls as well as a complete parts list with exploded view diagrams. I have two of these machines in my shop, and I've enjoyed using them over the years.
Safety Rules For All Tools...............................3
Additional Safety Rules For Shapers......................3
Unpacking And Setting Up.................................4
Motor....................................................4
Grounding Information....................................4
Overload Protection......................................5
Switch...................................................5
Equipment Furnished With Your Machine
When Used As A Router....................................5
When Used As A Shaper....................................5
Operating Controls For Motor And Spindle Assembly........6
Operating Controls For Table.............................6
Operating Controls For The Fence.........................7
Routing When Using The Fence As A Guide..................7
Guide Pin Routing........................................9
Changing Machine From Router To Shaper Position.........10
Shaping When Using The Fence As A Guide.................11
Shaping With Collars And Starting Pin...................12
Position Of Collars.....................................12
Starting Pin............................................13
Adjusting Table Gib.....................................14
Brush Inspection........................................14
Motor And Spindle Assembly..............................14
Inspecting And Replacing Coupling And Spider On
Motor And Spindle Assembly..............................15
Recommended Extension Cord Sizes........................15
How To Order Replacement Parts..........................17
Accessories.........................................18, 19
Rockwell Service Centers................................20
