3 KVA Electro Arc 2SE TAP DISINTEGRATER, LBH PORTbl DIS
3 KVA Electro Arc 2SE TAP DISINTEGRATER, LBH PORTABLE DISINTEGRATOR HEAD
MODEL: 2-SE S/N: 1608 NEW: 1981
OVERALL SIZE .............................. 15" X 16"
"T" SLOTS ON WORK SURFACE (3) .................. 1/2"
DISINTEGRATOR HEAD ............................ 17"
RADIAL COLUMN (HARD CHROME PLATED):
DIAMETER ..................................... 2-1/2"
LENGTH .......................................... 15"
ROTATION .......................... 360 IN TWO PLANES
VERTICAL COLUMN (HARD-CHROME PLATED):
DIAMETER ..................................... 2-3/4"
HEIGHT .......................................... 36"
CUTTING SPEEDS (APPROXIMATE): REMOVAL TIME:
BROKEN TAPS 1-INCH DEEP: 1/4" - 1 MIN
POSITIVE DOWNSTROKES PER SECOND .................. 60
AUTOMATIC GRAVITY SPRING FEED HAS 9" OF VERTICAL TRVL
#LBH PORTABLE DISINTEGRATOR HEAD
SINGLE PHASE 120 VOLT ELECTRICS
APPROXIMATE WEIGHT ............................ 360 LBS
